We design milk white PC cover to stop glare perfectly.
1.The high quality power driver is
2.We use special LED chip package method and Schistic aluminum radiator to solve the heatout problem more perfectly.
3.The lamp test result keeps 76lm/W,made up by intergrated LEDs module.if one LEDs series is damaged,the
other LEDs will keep on work .
4.With only 3.8Kg net weight to help your installation more easy.
5.We guarantee the electrical fan lifespan to be 65,000 hours.
6.Design 20pcs LEDs to keep lighting equally distributed reduce light spot on the ground.
| Item | D-20-100/4-H | D-20-160/4-H |
| Power | 100W | 160W |
| Lumen | 11,150 lm | 18,400lm |
| Luminous Efficacy | 76lm/W | |
| Voltage | 100V-240VAC | |
| Current | 300mA | |
| Frequency | 50Hz / 60Hz | |
| Power Factor | Power factor:>0.95 | |
| DC power factor | 84%min.(input 100Vac) 85%min.(input 220Vac) |
|
| luminous decay | <6% in 1000hours,<20% in 2500 hours | |
| Color temp. | 3500K~ 6500K | |
| Ra | Ra>73 | |
| Lifespan | 50000 h | |
| Working temperature. | - 40degree~ + 50degree | |
| LED chip Chip junction temperature | <58 degree | |
| working temperature | <50 degree | |
| Working humidity | 10% ~ 90% | |
| Material | aluminium alloy | |
| Ip grade | 54 | |
| Beam angle | 120 degree | |
| Body color | silver gray | |
| Size | 470*385mm | |
| Net weight | 3.8kg | |
| Gross weight | 6.9Kg | |
| Package size | 53*53*46cm | |
