Stainless Steel Wider Woven Wire Cloth
The Material Have SS 304, 304l, 316, 316l .
The Weaving Type: Plain Weave, Twill Weave .
The Roll Width: 2m-6m .
The Roll Long: 10m/15m/20m.
This types Stainless steel wider wire mesh is made of the Stainless Steel wire to woven by large
woven machines To made the square hole with plain Twill weave,The Extra Wide Stainless Steel
Woven Wire Mesh Or stainless steel super wide mesh surface and hole is very nice ,suitable for
paper industrial.
|
Mesh
|
Wire Gauge
|
Aperture
|
Percentage of Opening(%)
|
Roll Width
|
||
|
inch
|
mm
|
inch
|
mm
|
|||
|
20×20
|
0.016
|
0.406
|
0.034
|
0.864
|
46.2
|
7'－19.6'
(2-6 meter) |
|
30×30
|
0.012
|
0.305
|
0.021
|
0.542
|
39.7
|
|
|
40×40
|
0.010
|
0.254
|
0.015
|
0.381
|
36.4
|
|
|
50×50
|
0.008
|
0.203
|
0.012
|
0.305
|
36.0
|
|
|
60×60
|
0.007
|
0.178
|
0.010
|
0.254
|
33.9
|
|
|
80×80
|
0.0055
|
0.140
|
0.007
|
0.178
|
25.4
|
|
|
100×100
|
0.0043
|
0.109
|
0.0057
|
0.145
|
32.5
|
|
|
Remark: other sizes not listed can be produced upon request.
|
||||||
