Specifications
|
|
|
Spindle diameter
|
160mm
|
|
Diameter of milling spindle
|
240mm
|
|
Spindle speed
|
10-1200r/min
|
|
Spindle taper
|
ISO50 7:24
|
|
Power of Spindle motor
|
30/37KW
|
|
Shank
|
DIN69871A
|
|
Pull stud
|
LDA-50
|
|
Transverse travel of table X
|
3000mm
|
|
Vertical travel of spindle head Y
|
2000mm
|
|
Longitudinal travel of column Z
|
1500mm
|
|
Axial travel of spindle W
|
900mm
|
|
Table rotation（any angle）B
|
360°
|
|
Table size
|
2000×2000mm
|
|
Max. load
|
20000kg
|
|
Rapid traverse X, Y, Z
W,U
|
10000 6000mm/min
5000 1000mm/min
|
|
Rapid rotation
|
2r/min
|
|
Feedrate X, Y, Z
W,U
|
1-5000mm/min
1-3000 1-500mm/min
|
|
Rotation rate B
|
0.005-1.5r/min
|
|
Spindle torque
|
2800Nm
|
|
Torque of milling spindle
|
3500Nm
|
|
Feed resisting force X,Y,Z, W
|
35000N
|
|
Positioning accuracy X, Y, Z,W
B
|
±0.025mm
±5 ″
|
|
Repeatability X Y Z W
B
|
±0.02mm
±3″
|
|
CNC system
|
802(F0i)
|
|
Weight
|
58000kg
|
