Standard temperature air inlet [ IDF1E, 2E, 3E, 4E, 6E, 8E, 11E, 15E1, 22E, 37E, 55E, 75E, 120D, 150D, 190D, 240D, 370B
High temperature air inlet [ IDU3E, 4E, 6E, 8E, 11E, 15E1, 22E, 37E, 55E, 75E
Improved corrosion resistance
with the stainless steel heat exchanger
(IDF4E to 75E/IDU3E to 75E)
Zero ozone depletion potential
Refrigerant
Up to
Air flow
Up to
Power
R407C (HFC)
R134a (HFC)
(SMC comparison) (SMC comparison)
Series
Refrigerated Air Dryers
An air dryer removes the vapor from the moist compressed air delivered by the
compressor, and prevents it from causing the pneumatic equipment to fail.
Protect Pneumatic Equipment from Moisture!
Effects of moisture on equipment
Decomposition of auto drain
caused by rusting inside pipes
Malfunctioning of valves and Generation of water droplets
actuators caused by dripping grease
CAT.ES30-8F
