Product Description :

Detailed Product Description

1) Membrane Type : Polyamide TFC
2) Maximum pressure drop : 150 psi
3) Permeate Flow Rate : 9,000 gpd

DOW FILMTEC RO MEMBRANE HSRO-390 FF

Features:

HSRO elements, manufactured on advanced automated equipment, have the highest active membrane area available in the industry today. This high area allows system designs with either lower operating flux or cost savings from fewer membrane elements. The full-fit configuration minimizes stagnant areas and is an ideal choice for applications requiring a sanitary design. All components comply with U.S. Food & Drug Administration standards

Specifications:

Product name	HSRO-390FF
Part number	170701
Nominal Active Surface Area	390 (36) ft2 (m2)
Applied Pressure	150 (10.3)
Permeate Flow Rate	9,000 (34) gpd (m3/d)
Stabilized Salt Rejection	99.5 %
1. HSRO-4040-FF was previously named SG30-85-HS. HSRO-390-FF was previously named SG30-390-HS. 2. Permeate flow and salt rejection based on the following test conditions: 2,000 ppm NaCl, pressure specified above, 77°F (25°C ) and 15% recovery. 3. Elements must be conditioned prior to start-up. A one-time flux loss will occur during stabilization. Listed values apply after performance stabilization. 4. Permeate flows for individual elements may vary +/-20%. 5. For the purpose of improvement, specifications may be updated periodically.
Membrane Type	Polyamide Thin-Film Composite (Filmtech)
Maximum Operating Temperature	113°F (45°C)
Maximum pressure drop	15 psig (1.0 bar)
pH Range, Continuous Operation	3-10
pH Range, Short Term Cleaning	1-12
Maximum Feed Silt Density Index	SDI 5
