PTFE MOLDING POWDER RESIN (4S01)
INTRODUCTION
4S01 is designed for use in molding which is white granular PTFE resin, with excellent chemical stability electrical property and low frictional coefficient. It can be used unchanged with the long term temperature range of -250----260.
PRODUCT ITEM
GRADE APPLICATION
4S01-A High----performance rods, sheets and films
4S01-B High----performance small parts, profiles
4S01-C General----molding parts
PROPERTY OF PRODUCT
TENSILE STREDNTH, MPa
4S01—A min25.5 4S01—B min25.5 4S01—C min 22.5
ELONGGATION, min 250 percent
BULK DENSITY, g/l 500
PRTICLE SIZE μm 180
MOISTURE, max 0.04 percent
MELTING POINT,? 327 degree
MORMAL SPECIFIC GRAVITY 2.13-2.18
THERMAL INSTABILITY INEDX min 50
ELECTRIC STRENGTH, MV/m 60
