Principle
The IPL Quantum Skin-cleaning System emits varied wavelength, intense pulse, and broad-spectrum quantized photon-current. It can permeate the cuticle to the derma and take effect on the abnormal pigment and vessel such target tissues to break the abnormal pigment cells, close the abnormal blood vessels, stimulate the proliferation of collagen and improving the rearrangement of elastic fibers, finally achieving the purpose of pigment removal and skin rejuvenation.
Indication
Speckles, age spot, sun-induced freckles and so on
Red blood streak, acne rosacea, erythema
Wrinkles, acne scar, low skin elasticity, Trichopore
Skin rejuvenating, Hair-removal
Treatment traits
Broad-spectrum, no ablation or intervention to skin
System feature
Three Treatment handles with broad indication
Effective Cooling system- Thermal & electric cooled, Built-in circle water cooled, air cooled
LCD Screen with function keys for easy control
Efficient energy emitting for shorter treatment
Specifications
Wavelength: HR: 690nm-1200nm
SR: 560nm-1200nm
VR: 420nm-1200nm
Light guide: Crystal optical system
Fluence: 20-50m/cm²
Pulse duration: 9.7ms
Fluency: ≿p/2S
Spot size: 8×34mm
Cooling system: Thermal & Electric and Built-in Circle water-cooling system
Net weight: 45kg
Packing weight: 80kg
Size : 850×900×500mm
Packing size: 1100mm×910mm×600mm
Power requirement: AC 110-240V, 3A, 50HZ
