| Type One Touch |
Cat 20 |
Super light
CAL 10 Series |
| Body Material |
Steel Chrome plated |
Socket Brass Chrome plated Plug Steel Chrome plated |
| Sear Material |
Standard NBR Optional Viton |
| Max Pressure |
1.5MPa |
| Hose/Thread Size |
1/4", 3/8", 1/2" |
1/8", 1/4" |
|
| Type L |
|
| Type CAL/CAT |
2L |
5L |
2WRL |
| Inlet/Outlet |
CAL22PM/
CAL22SM |
CAL44PM/
CAL22/24SM |
CAL22PM/
CAL22SM |
| Attachment |
CAL22PHx2 |
CAL22PHx4/
CAL44SHx1 |
CAL22PHx2 |
| Max Pressure |
2.0MPa |
|
|
|
| Type CCH Urethan Coil Hose (with couplers) |
| Coupler Deal Material |
NBR |
| General Working Pressure |
0.7MPa |
| Hose Diameter Size (mm) |
5x8, 6.5x10,
8x12, 11x16 |
| Hose Working Length (m) |
2.0, 4.0,
6.0, 8.0 |
|
| Type CKC (water line) |
| Body Material |
Brass |
| Seal Material |
Standard Viton |
| Max Pressure |
1.5MPa |
| Hose/Thread size |
1/8", 1/4" |
|
| Type CTL (Straight Through) |
| Body Material |
Stell Zink plated Brass
Stainless 304 and 316 |
| Seal Material |
Standard Viton Optional
NBR and others |
| Max Pressure |
2.0 - 10OMPa according
to body size and material. |
Hose/
Thread Size |
1/8", 1/4", 3/8", 1/2", 3/4",
1", 1-1/4", 1-1/2",1-3/4", 2" |
|
| Type CSP (2 Way Shut-Off) |
| Body Material |
Steel Zink Plated,
Brass Stainless 304 and 316 |
| Seal Material |
Standard Viton from 1/2" to
2" Option NBR and others |
Standard NBR from 1/8" to
3/8" Option Viton and others |
| Max pressure |
2.0-10.0MPa according
to body size and material |
| Thread size |
1/8", 1/4", 3/8", 1/2", 3/4",
1", 1-1/4", 1-1/2", 1-3/4". 2" |
|
| Type CHP (2 way shut-off) |
| Body Material |
Special Steel Zink plated
(option Nickel plated) |
| Seal Material |
Standard NBR, Option Viton |
| Max Pressure |
20.5-31.0 Mpa according
to body size and material |
| Thread size |
1/8", 1/4", 3/8", 1/2", 3/4",
1", 1-1/4", 1-1/2", 1-3/4", 2" |
|
| Custom-made Couplers |
| Designed upon your requests |
|
