Advantages：
Long life time:14000h
High tension, not easily damaged
Weave structure, easily cleaned
More heat contain and beteer moisture absorbed
High air permeability
High friction function
Ensure the self-adjustment on different corrugating machine
Lower noise during production
Ensure the edges are in good condition
Hot jaw and lacing part are stronger and long time
No franklinism
Middle Speed corrugator Belt
Middle Speed corrugator Belt is 5 layer structure belt, each structure of the layer are the same, each layer has the same material, and the absorbent fiber is woven into the surface layer, made of the high grade PET continuous filament yarn with high tension and low flexibility. The surface is straight line, then, in return, guarantee correct gluing and fast drying of the board. Our specifical structure design ensure the hydrophilic and drying ability.
Products Features:
Fasteners Cliper Steel
High Tensile strenght
Heat resistance
Good moisture absorption
Excellent air pemeability
stability dimension
Suitable for linear speed 100 -180m/min
Long life time
Specifications:
Model:ZSD-10
Material:PET100%
Applt speed:150m/min.
Thickness:(10±0.3)mm
Wideth:(1200-2900)mm
Tension:63Mpa
Heat-resistance:under200℃,accept short time pressure
under150℃,accept long time pressure
Coefficient of friction:≥0.35μ
Weight per unit:(4±0.2)kg/m2
Min. winding radius:R75mm
Air-permeability:1.95M3/M2
Life:14000h
Price: FOB 80-100USD/m2
Port::Xingang
Date of delivery:15-30days
High speed corrugator Belt
High speed corrugator Belt was developed to high speed running and rapid dying of the corrugated board. The structure and the quality of the belt facilitates steam evaporation from the paperboard. The belt is 3-layer belt. The structure of two surface layers are not the same as the middle layer. This structure is developed to produce flat boards on high-speed corrugating machines. The surface of the belt is twill weave to reduce the noise when high speed running on the machine,increase the friction coefficient.
Products Features:
Straight cut edge
Level surface, clean mark
Fasteners Cliper Steel
High Tensile strenght
Heat resistance
Good moisture absorption
Excellent air pemeability
stability dimension
Suitable for linear speed 200-260m/min
Low noise and high speed of operation
Long life time
Specifications:
Model:WSD/GS-9
Material:PET100%
Applt speed:260m/min.
Thickness:(9±0.3)mm
Wideth:(1200-2900)mm
Tension:60Mpa
Heat-resistance:under200℃,accept short time pressure
under150℃,accept long time pressure
Weight per unit:(7±0.3)kg/m2
Min. winding radius:R70mm
Air-permeability:1.95M3/M2
Life:14000h
Price: FOB 80-100USD/m2
Port::Xingang
Date of delivery:15-30days
High speed corrugator Belt with kevlar
High speed corrugator Belt with kevlar edge is a consistent development bason on the high speed corrugator belt. It is ideal for corrugating systems with high production speed, even load systems and frequently changing paperboard widths. The belt's edge reinforcement of kevlar fibers reduce wear substantially and ensure a mor e long life time.
Products Features:
Straight cut edge
Level surface, clean mark
Fasteners Cliper Steel
High Tensile strenght
Heat resistance
Good moisture absorption
Excellent air pemeability
stability dimension
Suitable for linear speed 200-260m/min
High moisture absorption and release
Low noise and high speed of operation
Long life time
Specifications:
Model:WSD/GS-9
Material:PET100%
Applt speed:260m/min.
Thickness:(9±0.3)mm
Wideth:(1200-2900)mm
Tension:60Mpa
Heat-resistance:under200℃,accept short time pressure
under150℃,accept long time pressure
Coefficient of friction:0.42μ
Weight per unit:(7±0.3)kg/m2
Min. winding radius:R70mm
Air-permeability:1.95M3/M2
Life:14000h
Price: FOB 80-100USD/m2
Port::Xingang
Date of delivery:15-30days
Tel: 86-311-80772027
E-mail: troy.l@huataogroup.com
Skype: huataobelt@outlook.com
Website:www.htwirebelt.com
Add: No.298,North Zhonghua Street, Shijiazhuang,Hebei,China
Huatao Wire Belt Factory
