The LHT-HDO5B 5-megapixel HDR monocular wide-angle recording and video camera module features a 1/2.5" CMOS image sensor and supports recording and video at resolutions up to 2592 x 1944 pixels at 30 fps. Its high frame rate and high dynamic range ensure smooth and clear video.
The LHT-HDO5B camera module offers HDR and low-light performance, a built-in microphone, and a voice pickup range of up to 3 meters. This UVC-compliant, plug-and-play camera module is compatible with Windows, Linux, and Android operating systems and is suitable for machine vision, industrial inspection, video conferencing, and other applications.
Technical Parameters:
Image Sensor | 1/2.5 ”CMOS | ||
Effective Pixels | 2592*1944 | ||
Pixel size | 2.2umx2.2um | ||
Video output | MJPG YUY2 | ||
Maximum Frame Rates(MJPG Resolution and Frame Rate) | 2592*1944/25fps | ||
Maximum Frame Rates(YUY2 Resolution and Frame Rate) | 2592*1944/5fps | ||
Dynamic range | ≤100dB | ||
Digital interface | 5-pin 1.25mm USB2.0 | ||
Power requirements | 5V+-0.5 | ||
Power Consumption | 2W | ||
Dimensions mm | 35.5mmx30mm | ||
Operatingtemperature(℃) | -15~60℃ | ||
Monochrome camera modules are indispensable components in application scenarios that demand high sensitivity, precise contrast, and accurate image capture.
